AudioMuse-AI

AudioMuse-AI is a Dockerized environment that brings smart playlist generation to Jellyfin using deep audio analysis via Essentia with TensorFlow. All you need is in a container that you can deploy locally or on your Kubernetes cluster (tested on K3S). In this repo, you also have a /deployment/deployment.yaml example that you need to configure following the configuration parameter chapter.

The main scope of this application is testing the clustering algorithm. A front-end is provided for easy use. You can also find the stand-alone Python script in the Jellyfin-Essentia-Playlist repo.

Addional important information on this project can also be found here: * Brief slide presentation: docs/slide.pdf. * Mkdocs version of this README.md for better visualizzation: Neptunehub AudioMuse-AI DOCS

IMPORTANT: This is an BETA (yes we passed from ALPHA to BETA finally!) open-source project I’m developing just for fun. All the source code is fully open and visible. It’s intended only for testing purposes, not for production environments. Please use it at your own risk. I cannot be held responsible for any issues or damages that may occur.

Table of Contents

Quick Start on K3S

This section provides a minimal guide to deploy AudioMuse-AI on a K3S (Kubernetes) cluster.

  1. Prerequisites:

    • A running K3S cluster.
    • kubectl configured to interact with your cluster.

  2. Configuration:

    • Navigate to the deployments/ directory.
    • Edit deployment.yaml to configure mandatory parameters:
      • Secrets:
        • jellyfin-credentials: Update api_token and user_id.
        • postgres-credentials: Update POSTGRES_USER, POSTGRES_PASSWORD, and POSTGRES_DB.
        • gemini-api-credentials (if using Gemini for AI Naming): Update GEMINI_API_KEY.
      • ConfigMap (audiomuse-ai-config):
        • Update JELLYFIN_URL.
        • Ensure POSTGRES_HOST, POSTGRES_PORT, and REDIS_URL are correct for your setup (defaults are for in-cluster services).
  3. Deploy: bash kubectl apply -f deployments/deployment.yaml
  4. Access:
    • Main UI: Access at http://<EXTERNAL-IP>:8000
    • API Docs (Swagger UI): Explore the API at http://<EXTERNAL-IP>:8000/apidocs

Kubernetes Deployment (K3S Example)

The Quick Start provided in the playlist namespace the following resources:

Pods (Workloads): * audiomuse-ai-worker: Runs the background job processors using Redis Queue. It's recommended to run a minimum of 2 replicas to ensure one worker can handle main tasks while others manage subprocesses, preventing potential stalls. You can scale this based on your cluster size and workload. * audiomuse-ai-flask: Hosts the Flask API server and the web front-end. This is the user-facing component. * postgres-deployment: Manages the PostgreSQL database instance, which persists analyzed track data, playlist structures, and task status. * redis-master: Provides the Redis instance used by Redis Queue to manage the task queue.

Services (Networking): * audiomuse-ai-flask-service: A LoadBalancer service that exposes the Flask front-end externally. You can access the web UI via the external IP assigned to this service on port 8000. Consider changing this to ClusterIP if you plan to use an Ingress controller. * postgres-service: A ClusterIP service allowing internal cluster communication to the PostgreSQL database from the worker and flask pods. * redis-service: A ClusterIP service allowing internal cluster communication to the Redis instance from the worker and flask pods.

Secrets (Sensitive Configuration): * jellyfin-credentials: Stores your sensitive Jellyfin api_token and user_id. You must update this Secret with your actual values. * postgres-credentials: Stores the sensitive PostgreSQL POSTGRES_USER, POSTGRES_PASSWORD, and POSTGRES_DB credentials. You must update this Secret with your actual values. * gemini-api-credentials: Stores your GEMINI_API_KEY if you configure the application to use Google Gemini for AI playlist naming. Update this Secret if you plan to use Gemini.

ConfigMap (Non-Sensitive Configuration): * audiomuse-ai-config: Contains non-sensitive application parameters passed as environment variables. By default, this includes JELLYFIN_URL, POSTGRES_HOST, POSTGRES_PORT, and REDIS_URL. You must update JELLYFIN_URL with your Jellyfin server's address. Ensure POSTGRES_HOST, POSTGRES_PORT, and REDIS_URL match the internal service names if you modify the deployment structure.

PersistentVolumeClaim (Data Persistence): * postgres-pvc: This is crucial for ensuring your PostgreSQL database data persists across pod restarts or redeployments. Review and ensure its configuration is appropriate for your environment to prevent data loss. Regularly backing up the database is also highly recommended.

The deployment file also creates the playlist namespace to contain all these resources.

For a more stable use, I suggest editing the deployment container image to use specific version tags, for example, ghcr.io/neptunehub/audiomuse-ai:0.2.2-alpha.

Configuration Parameters

These are the parameters accepted for this script. You can pass them as environment variables using, for example, /deployment/deployment.yaml in this repository.

The mandatory parameter that you need to change from the example are this:

Parameter Description Default Value
JELLYFIN_URL (Required) Your Jellyfin server's full URL http://YOUR_JELLYFIN_IP:8096
JELLYFIN_USER_ID (Required) Jellyfin User ID. (N/A - from Secret)
JELLYFIN_TOKEN (Required) Jellyfin API Token. (N/A - from Secret)
POSTGRES_USER (Required) PostgreSQL username. (N/A - from Secret)
POSTGRES_PASSWORD (Required) PostgreSQL password. (N/A - from Secret)
POSTGRES_DB (Required) PostgreSQL database name. (N/A - from Secret)
POSTGRES_HOST (Required) PostgreSQL host. postgres-service.playlist
POSTGRES_PORT (Required) PostgreSQL port. 5432
REDIS_URL (Required) URL for Redis. redis://redis-service.playlist:6379/0
GEMINI_API_KEY (Required if AI_MODEL_PROVIDER is GEMINI) Your Google Gemini API Key. (N/A - from Secret)

These parameter can be leave as it is:

Parameter Description Default Value
TEMP_DIR Temp directory for audio files /app/temp_audio

This are the default parameters on wich the analysis or clustering task will be lunched. You will be able to change them to another value directly in the front-end:

Parameter Description Default Value
Analysis General
NUM_RECENT_ALBUMS Number of recent albums to scan (0 for all). 2000
TOP_N_MOODS Number of top moods per track for feature vector. 5
Clustering General
CLUSTER_ALGORITHM Default clustering: kmeans, dbscan, gmm. kmeans
MAX_SONGS_PER_CLUSTER Max songs per generated playlist segment. 40
MAX_SONGS_PER_ARTIST Max songs from one artist per cluster. 3
MAX_DISTANCE Normalized distance threshold for tracks in a cluster. 0.5
CLUSTERING_RUNS Iterations for Monte Carlo evolutionary search. 1000
Evolutionary Clustering & Scoring
TOP_N_ELITES Number of best solutions kept as elites. 10
EXPLOITATION_START_FRACTION Fraction of runs before starting to use elites. 0.2
EXPLOITATION_PROBABILITY_CONFIG Probability of mutating an elite vs. random generation. 0.7
MUTATION_INT_ABS_DELTA Max absolute change for integer parameter mutation. 3
MUTATION_FLOAT_ABS_DELTA Max absolute change for float parameter mutation. 0.05
MUTATION_KMEANS_COORD_FRACTION Fractional change for KMeans centroid coordinates. 0.05
SCORE_WEIGHT_DIVERSITY Weight for inter-playlist mood diversity. 0.6
SCORE_WEIGHT_PURITY Weight for intra-playlist mood consistency. 0.4
SCORE_WEIGHT_OTHER_FEATURE_DIVERSITY Weight for inter-playlist 'other feature' diversity. 0.3
SCORE_WEIGHT_OTHER_FEATURE_PURITY Weight for intra-playlist 'other feature' consistency. 0.2
SCORE_WEIGHT_SILHOUETTE Weight for Silhouette Score (cluster separation). 0.6
SCORE_WEIGHT_DAVIES_BOULDIN Weight for Davies-Bouldin Index (cluster separation). 0.0
SCORE_WEIGHT_CALINSKI_HARABASZ Weight for Calinski-Harabasz Index (cluster separation). 0.0
K-Means Ranges
NUM_CLUSTERS_MIN Min $K$ for K-Means. 20
NUM_CLUSTERS_MAX Max $K$ for K-Means. 60
DBSCAN Ranges
DBSCAN_EPS_MIN Min epsilon for DBSCAN. 0.1
DBSCAN_EPS_MAX Max epsilon for DBSCAN. 0.5
DBSCAN_MIN_SAMPLES_MIN Min min_samples for DBSCAN. 5
DBSCAN_MIN_SAMPLES_MAX Max min_samples for DBSCAN. 20
GMM Ranges
GMM_N_COMPONENTS_MIN Min components for GMM. 20
GMM_N_COMPONENTS_MAX Max components for GMM. 60
GMM_COVARIANCE_TYPE Covariance type for GMM (task uses 'full'). full
PCA Ranges
PCA_COMPONENTS_MIN Min PCA components (0 to disable). 0
PCA_COMPONENTS_MAX Max PCA components. 5
AI Naming (*)
AI_MODEL_PROVIDER AI provider: OLLAMA, GEMINI, or NONE. GEMINI
OLLAMA_SERVER_URL URL for your Ollama instance (if AI_MODEL_PROVIDER is OLLAMA). http://<your-ip>11434/api/generate
OLLAMA_MODEL_NAME Ollama model to use (if AI_MODEL_PROVIDER is OLLAMA). mistral:7b
GEMINI_MODEL_NAME Gemini model to use (if AI_MODEL_PROVIDER is GEMINI). gemini-1.5-flash-latest
GEMINI_API_CALL_DELAY_SECONDS Seconds to wait between Gemini API calls to respect rate limits. 7
PCA_COMPONENTS_MIN Min PCA components (0 to disable). 0
PCA_COMPONENTS_MAX Max PCA components. 5

(*) For using GEMINI API you need to have a Google account, a free account can be used if needed. Instead if you want to self-host Ollama here you can find a deployment example:

  • https://github.com/NeptuneHub/k3s-supreme-waffle/tree/main/ollama

Local Deployment with Docker Compose

For a quick local setup or for users not using Kubernetes, a docker-compose.yaml file is provided in the deployment/ directory.

Prerequisites: * Docker and Docker Compose installed.

Steps: 1. Navigate to the deployment directory: bash cd deployment 2. Review and Customize (Optional): The docker-compose.yaml file is pre-configured with default credentials and settings suitable for local testing. You can edit environment variables within this file directly if needed (e.g., JELLYFIN_URL, JELLYFIN_USER_ID, JELLYFIN_TOKEN). 3. Start the Services: bash docker compose up -d --scale audiomuse-ai-worker=2 This command starts all services (Flask app, RQ workers, Redis, PostgreSQL) in detached mode (-d). The --scale audiomuse-ai-worker=2 ensures at least two worker instances are running, which is recommended for the task processing architecture. 4. Access the Application: Once the containers are up, you can access the web UI at http://localhost:8000. 5. Stopping the Services: bash docker compose down

Docker Image Tagging Strategy

Our GitHub Actions workflow automatically builds and pushes Docker images. Here's how our tags work:

  • :latest
  • Builds from the main branch.
  • Represents the latest stable release.
  • Recommended for most users.
  • :devel
  • Builds from the devel branch.
  • Contains features still in development, not fully tested, and they could not work.
  • Use only for development.
  • :vX.Y.Z (e.g., :v0.1.4-alpha, :v1.0.0)
  • Immutable tags created from specific Git releases/tags.
  • Ensures you're running a precise, versioned build.
  • Use for reproducible deployments or locking to a specific version.

Important version * 0.1.5-alpha - Last version with the use of Sqlite and Celery. Only 1 worker admitted. * To deploy you can download the source code from here and use the appropriate deployment.yaml example: https://github.com/NeptuneHub/AudioMuse-AI/releases/tag/v0.1.5-alpha

Workflow Overview

This is the main workflow of how this algorithm works. For an easy way to use it, you will have a front-end reachable at your_ip:8000 with buttons to start/cancel the analysis (it can take hours depending on the number of songs in your Jellyfin library) and a button to create the playlist.

  • User Initiation: Start analysis or clustering jobs via the Flask web UI.
  • Task Queuing: Jobs are sent to Redis Queue for asynchronous background processing.
  • Parallel Worker Execution:
    • Multiple RQ workers (at least 2 recommended) process tasks in parallel. Main tasks (e.g., full library analysis, entire evolutionary clustering process) often spawn and manage child tasks (e.g., per-album analysis, batches of clustering iterations).
    • Analysis Phase:
      • Workers fetch metadata and download audio from Jellyfin, processing albums individually.
      • Essentia and TensorFlow models analyze tracks for features (tempo, key, energy) and predictions (genres, moods, etc.).
      • Analysis results are saved to PostgreSQL.
    • Clustering Phase:
      • An evolutionary algorithm performs numerous clustering runs (e.g., K-Means, DBSCAN, or GMM) on the analyzed data. It explores different parameters to find optimal playlist structures based on a comprehensive scoring system.
  • Playlist Generation & Naming:
    • Playlists are formed from the best clustering solution found by the evolutionary process.
    • Optionally, AI models (Ollama or Gemini) can be used to generate creative, human-readable names for these playlists.
    • Finalized playlists are created directly in your Jellyfin library.
  • Advanced Task Management:
    • The web UI provides real-time monitoring of task progress, including main and sub-tasks.
    • A key feature is the ability to cancel tasks (both parent and child) even while they are actively running, offering robust control over long processes. This is more advanced than typical queue systems where cancellation might only affect pending tasks.

Analysis Algorithm Deep Dive

The audio analysis in AudioMuse-AI, orchestrated by tasks.py, meticulously extracts a rich set of features from each track. This process is foundational for the subsequent clustering and playlist generation. 1. Audio Loading & Preprocessing: * Tracks are first downloaded from your Jellyfin library to a temporary local directory. Essentia's MonoLoader is then employed to load the audio. * A crucial preprocessing step involves resampling the audio to a consistent 16000 Hz sample rate with a resampleQuality of 4. This standardization is vital because the subsequent TensorFlow models are trained on and expect audio at this specific sample rate, ensuring accurate feature extraction.

  1. Core Feature Extraction (Essentia):

    • Tempo: The RhythmExtractor2013 algorithm analyzes the rhythmic patterns in the audio to estimate the track's tempo, expressed in Beats Per Minute (BPM).
    • Key & Scale: The KeyExtractor algorithm identifies the predominant musical key (e.g., C, G#, Bb) and scale (major or minor) of the track. This provides insights into its harmonic structure.
    • Energy: Essentia's Energy function calculates the raw total energy of the audio signal. However, to make this feature comparable across tracks of varying lengths and overall loudness, the system computes and stores the average energy per sample (total energy divided by the number of samples). This normalized energy value offers a more stable representation of the track's perceived loudness or intensity.

  2. Embedding Generation (TensorFlow & Essentia):

    • MusiCNN Embeddings: The cornerstone of the audio representation is a 200-dimensional embedding vector. This vector is generated using TensorflowPredictMusiCNN with the pre-trained model msd-musicnn-1.pb (specifically, the output from the model/dense/BiasAdd layer). MusiCNN is a Convolutional Neural Network (CNN) architecture that has been extensively trained on large music datasets (like the Million Song Dataset) for tasks such as music tagging. The resulting embedding is a dense, numerical summary that captures high-level semantic information and complex sonic characteristics of the track, going beyond simple acoustic features.

  3. Prediction Models (TensorFlow & Essentia): The rich MusiCNN embeddings serve as the input to several specialized TensorflowPredict2D models, each designed to predict specific characteristics of the music:

    • Primary Tag/Genre Prediction:
      • Model: msd-msd-musicnn-1.pb
      • Output: This model produces a vector of probability scores. Each score corresponds to a predefined tag or genre from a list (defined by MOOD_LABELS in config.py, including labels like 'rock', 'pop', 'electronic', 'jazz', 'chillout', '80s', 'instrumental', etc.). These scores indicate the likelihood of each tag/genre being applicable to the track.
    • Other Feature Predictions: The predict_other_models function leverages a suite of distinct TensorflowPredict2D models, each targeting a specific musical attribute. These models also take the MusiCNN embedding as input and typically use a model/Softmax output layer:
      • danceable: Predicted using danceability-msd-musicnn-1.pb.
      • aggressive: Predicted using mood_aggressive-msd-musicnn-1.pb.
      • happy: Predicted using mood_happy-msd-musicnn-1.pb.
      • party: Predicted using mood_party-msd-musicnn-1.pb.
      • relaxed: Predicted using mood_relaxed-msd-musicnn-1.pb.
      • sad: Predicted using mood_sad-msd-musicnn-1.pb.
      • Output: Each of these models outputs a probability score (typically the probability of the positive class in a binary classification, e.g., the likelihood the track is 'danceable'). This provides a nuanced understanding of various moods and characteristics beyond the primary tags.

  4. Feature Vector Preparation for Clustering (score_vector function): Before the actual clustering can occur, all the extracted and predicted features are meticulously assembled and transformed into a single numerical vector for each track. This is a critical step for machine learning algorithms:

    • Normalization: Tempo and the calculated average energy are normalized to a 0-1 range using configured minimum/maximum values (TEMPO_MIN_BPM, TEMPO_MAX_BPM, ENERGY_MIN, ENERGY_MAX). This ensures these features have a comparable scale.
    • Normalization:
      • Tempo (BPM) and the calculated average energy per sample are normalized to a 0-1 range. This is achieved by scaling them based on predefined minimum and maximum values (e.g., TEMPO_MIN_BPM = 40.0, TEMPO_MAX_BPM = 200.0, ENERGY_MIN = 0.01, ENERGY_MAX = 0.15 from config.py). Normalization ensures that these features, which might have vastly different original scales, contribute more equally during the initial stages of vector construction.
    • Vector Assembly:
      • The final feature vector for each track is constructed by concatenating: the normalized tempo, the normalized average energy, the vector of primary tag/genre probability scores, and the vector of other predicted feature scores (danceability, aggressive, etc.). This creates a comprehensive numerical profile of the track.
    • Standardization:
      • This complete feature vector is then standardized using sklearn.preprocessing.StandardScaler. Standardization transforms the data for each feature to have a zero mean and unit variance across the entire dataset. This step is particularly crucial for distance-based clustering algorithms like K-Means. It prevents features with inherently larger numerical ranges from disproportionately influencing the distance calculations, ensuring that all features contribute more equitably to the clustering process. The mean and standard deviation (scale) computed by the StandardScaler for each feature are saved. These saved values are essential later for inverse transforming cluster centroids back to an interpretable scale, which aids in understanding the characteristics of each generated cluster.

Persistence: PostgreSQL database is used for persisting analyzed track metadata, generated playlist structures, and task status.

Clustering Algorithm Deep Dive

AudioMuse-AI offers three algorithms, each suited for different scenarios when clustering music based on tempo and 5 mood scores. This clustering algorithm is executed multiple times (default 1000) following an Evolutionary Monte Carlo approach: in this way, multiple configurations of parameters are tested, and the best ones are kept.

Here's an explanation of the pros and cons of the different algorithms:

1. K-Means

  • Best For: Speed, simplicity, when clusters are roughly spherical and of similar size.
  • Pros: Very fast, scalable, clear "average" cluster profiles.
  • Cons: Requires knowing cluster count (K), struggles with irregular shapes, sensitive to outliers.

2. DBSCAN

  • Best For: Discovering clusters of arbitrary shapes, handling outliers well, when the number of clusters is unknown.
  • Pros: No need to set K, finds varied shapes, robust to noise.
  • Cons: Sensitive to eps and min_samples parameters, can struggle with varying cluster densities, no direct "centroids."

3. GMM (Gaussian Mixture Models)

  • Best For: Modeling more complex, elliptical cluster shapes and when a probabilistic assignment of tracks to clusters is beneficial.
  • Pros: Flexible cluster shapes, "soft" assignments, model-based insights.
  • Cons: Requires setting number of components, computationally intensive (can be slow), sensitive to initialization.

Recommendation: Start with K-Means for general use due to its speed in the evolutionary search. Experiment with GMM for more nuanced results. Use DBSCAN if you suspect many outliers or highly irregular cluster shapes. Using a high number of runs (default 1000) helps the integrated evolutionary algorithm to find a good solution.

Montecarlo Evolutionary Approach

AudioMuse-AI doesn't just run a clustering algorithm once; it employs a sophisticated Monte Carlo evolutionary approach, managed within tasks.py, to discover high-quality playlist configurations. Here's a high-level overview:

  1. Multiple Iterations: The system performs a large number of clustering runs (defined by CLUSTERING_RUNS, e.g., 1000 times). In each run, it experiments with different parameters for the selected clustering algorithm (K-Means, DBSCAN, or GMM) and for Principal Component Analysis (PCA) if enabled. These parameters are initially chosen randomly within pre-defined ranges.

  2. Evolutionary Strategy: As the runs progress, the system "learns" from good solutions:

    • Elite Solutions: The parameter sets from the best-performing runs (the "elites") are remembered.
    • Exploitation & Mutation: For subsequent runs, there's a chance (EXPLOITATION_PROBABILITY_CONFIG) that instead of purely random parameters, the system will take an elite solution and "mutate" its parameters slightly. This involves making small, random adjustments (controlled by MUTATION_INT_ABS_DELTA, MUTATION_FLOAT_ABS_DELTA, etc.) to the elite's parameters, effectively exploring the "neighborhood" of good solutions to potentially find even better ones.

  3. Comprehensive Scoring: Each clustering outcome is evaluated using a composite score. This score is a weighted sum of several factors, designed to balance different aspects of playlist quality:

    • Playlist Diversity: Measures how varied the predominant characteristics (e.g., moods, danceability) are across all generated playlists.
    • Playlist Purity: Assesses how well the songs within each individual playlist align with that playlist's central theme or characteristic.
    • Internal Clustering Metrics: Standard metrics evaluate the geometric quality of the clusters:
      • Silhouette Score: How distinct are the clusters?
      • Davies-Bouldin Index: How well-separated are the clusters relative to their intra-cluster similarity?
      • Calinski-Harabasz Index: Ratio of between-cluster to within-cluster dispersion.

  4. Configurable Weights: The influence of each component in the final score is determined by weights (e.g., SCORE_WEIGHT_DIVERSITY, SCORE_WEIGHT_PURITY, SCORE_WEIGHT_SILHOUETTE). These are defined in config.py and allow you to tune the algorithm to prioritize, for example, more diverse playlists over extremely pure ones, or vice-versa.

  5. Best Overall Solution: After all iterations are complete, the set of parameters that yielded the highest overall composite score is chosen. The playlists generated from this top-scoring configuration are then presented and created in Jellyfin.

This iterative and evolutionary process allows AudioMuse-AI to automatically explore a vast parameter space and converge on a clustering solution that is well-suited to the underlying structure of your music library.

AI Playlist Naming

After the clustering algorithm has identified groups of similar songs, AudioMuse-AI can optionally use an AI model to generate creative, human-readable names for the resulting playlists. This replaces the default "Mood_Tempo" naming scheme with something more evocative.

  1. Input to AI: For each cluster, the system extracts key characteristics derived from the cluster's centroid (like predominant moods and tempo) and provides a sample list of songs from that cluster.
  2. AI Model Interaction: This information is sent to a configured AI model (either a self-hosted Ollama instance or Google Gemini) along with a carefully crafted prompt.
  3. Prompt Engineering: The prompt guides the AI to act as a music curator and generate a concise playlist name (15-35 characters) that reflects the mood, tempo, and overall vibe of the songs, while adhering to strict formatting rules (standard ASCII characters only, no extra text).
  4. Output Processing: The AI's response is cleaned to ensure it meets the formatting and length constraints before being used as the final playlist name (with the _automatic suffix appended later by the task runner).

This step adds a layer of creativity to the purely data-driven clustering process, making the generated playlists more appealing and easier to understand at a glance. The choice of AI provider and model is configurable via environment variables and the frontend.

Concurrency Algorithm Deep Dive

AudioMuse-AI leverages Redis Queue (RQ) to manage and execute long-running processes like audio analysis and evolutionary clustering in parallel across multiple worker nodes. This architecture, primarily orchestrated within tasks.py, is designed for scalability and robust task management.

  1. Task Queuing with Redis Queue (RQ):

    • When a user initiates an analysis or clustering job via the web UI, the main Flask application doesn't perform the heavy lifting directly. Instead, it enqueues a task (e.g., run_analysis_task or run_clustering_task) into a Redis queue.
    • Separate RQ worker processes, which can be scaled independently (e.g., running multiple audiomuse-ai-worker pods in Kubernetes), continuously monitor this queue. When a new task appears, an available worker picks it up and begins execution.

  2. Parallel Processing on Multiple Workers:

    • This setup allows multiple tasks to be processed concurrently. For instance, if you have several RQ workers, they can simultaneously analyze different albums or run different batches of clustering iterations. This significantly speeds up the overall processing time, especially for large music libraries or extensive clustering runs.

  3. Hierarchical Task Structure & Batching for Efficiency: To minimize the overhead associated with frequent queue interactions (writing/reading task status, small job processing), tasks are structured hierarchically and batched:

    • Analysis Tasks: The run_analysis_task acts as a parent task. It fetches a list of albums and then enqueues individual analyze_album_task jobs for each album. Each analyze_album_task processes all tracks within that single album. This means one "album analysis" job in the queue corresponds to the analysis of potentially many songs, reducing the number of very small, granular tasks.
    • Clustering Tasks: Similarly, the main run_clustering_task orchestrates the evolutionary clustering. It breaks down the total number of requested clustering runs (e.g., 1000) into smaller run_clustering_batch_task jobs. Each batch task (e.g., run_clustering_batch_task) then executes a subset of these iterations (e.g., 10 iterations per batch). This strategy avoids enqueuing thousands of tiny individual clustering run tasks, again improving efficiency.

  4. Advanced Task Monitoring and Cancellation: A key feature implemented in tasks.py is the ability to monitor and cancel tasks even while they are actively running, not just when they are pending in the queue.

    • Cooperative Cancellation: Both parent tasks (like run_analysis_task and run_clustering_task) and their child tasks (like analyze_album_task and run_clustering_batch_task) periodically check their own status and the status of their parent in the database.
    • If a task sees that its own status has been set to REVOKED (e.g., by a user action through the UI) or if its parent task has been revoked or has failed, it will gracefully stop its current operation, perform necessary cleanup (like removing temporary files), and update its status accordingly.
    • This is more sophisticated than typical queue systems where cancellation might only prevent a task from starting. Here, long-running iterations or album processing loops can be interrupted mid-way.

  5. Status Tracking:

    • Throughout their lifecycle, tasks frequently update their progress, status (e.g., STARTED, PROGRESS, SUCCESS, FAILURE, REVOKED), and detailed logs into the PostgreSQL database. The Flask application reads this information to display real-time updates on the web UI.
    • RQ's job metadata is also updated, but the primary source of truth for detailed status and logs is the application's database.

Screenshots

Here are a few glimpses of AudioMuse AI in action (more can be found in /screnshot):

Analysis task

Screenshot of AudioMuse AI's web interface showing the progress of music analysis tasks.

Clustering task

Screenshot of AudioMuse AI's web interface showing the progress of music clustering tasks.

Key Technologies

AudioMuse AI is built upon a robust stack of open-source technologies:

  • Flask: Provides the lightweight web interface for user interaction and API endpoints.
  • Redis Queue (RQ): A simple Python library for queueing jobs and processing them in the background with Redis. It handles the computationally intensive audio analysis and playlist generation, ensuring the web UI remains responsive.
  • Essentia-tensorflow An open-source library for audio analysis, feature extraction, and music information retrieval. It's used here for:
  • MonoLoader: Loading and resampling audio files.
  • RhythmExtractor2013: Extracting tempo information.
  • KeyExtractor: Determining the musical key and scale.
  • TensorflowPredictMusiCNN & TensorflowPredict2D: Leveraging pre-trained TensorFlow models (like MusiCNN) for generating rich audio embeddings and predicting mood tags.
  • Essentia Models Leverages pre-trained models for feature extraction and prediction. More details and models.
    • Embedding Model:
      • msd-musicnn-1.pb: Used with TensorflowPredictMusiCNN for generating rich audio embeddings that capture high-level semantic information and complex sonic characteristics.
    • Classification Models: Used with TensorflowPredict2D for predicting various musical attributes from the generated embeddings:
      • msd-msd-musicnn-1.pb: For primary tag/genre prediction (e.g., 'rock', 'pop', 'electronic').
      • danceability-msd-musicnn-1.pb: For predicting danceability.
      • mood_aggressive-msd-musicnn-1.pb: For predicting aggressiveness.
      • mood_happy-msd-musicnn-1.pb: For predicting happiness.
      • mood_party-msd-musicnn-1.pb: For predicting party mood.
      • mood_relaxed-msd-musicnn-1.pb: For predicting relaxed mood.
      • mood_sad-msd-musicnn-1.pb: For predicting sadness.
  • scikit-learn Utilized for machine learning algorithms:
  • KMeans / DBSCAN: For clustering tracks based on their extracted features (tempo and mood vectors).
  • PCA (Principal Component Analysis): Optionally used for dimensionality reduction before clustering, to improve performance or cluster quality.
  • PostgreSQL: A powerful, open-source relational database used for persisting:
  • Analyzed track metadata (tempo, key, mood vectors).
  • Generated playlist structures.
  • Task status for the web interface.
  • Ollama Enables self-hosting of various open-source Large Language Models (LLMs) for tasks like intelligent playlist naming.
  • Google Gemini API: Provides access to Google's powerful generative AI models, used as an alternative for intelligent playlist naming.
  • Jellyfin API Integrates directly with your Jellyfin server to fetch media, download audio, and create/manage playlists.
  • Docker / OCI-compatible Containers – The entire application is packaged as a container, ensuring consistent and portable deployment across environments.

Additional Documentation

In audiomuse-ai/docs you can find additional documentation for this project, in details: * api_doc.pdf - Is a minimal documentation of the API in case you want to integrate it in your front-end (still work in progress) * docker_docs.pdf - Is a step-by-step documentation if you want to deploy everything on your local machine (debian) becuase you don't have a K3S (or other kubernetes) cluster avaiable. * audiomuse-ai/deployment/docker-compose.yaml - is the docker compose file used in the docker_docs.pdf

Future Possibilities

This MVP lays the groundwork for further development:

  • 💡 Integration into Music Clients: Directly used in Music Player that interacts with Jellyfin media server, for playlist creation OR instant mix;
  • 🖥️ Jellyfin Plugin: Integration as a Jellyfin plugin to have only one and easy-to-use front-end.
  • 🔁 Cross-Platform Sync Export playlists to .m3u or sync to external platforms.

Contributing

Contributions, issues, and feature requests are welcome!
This is an ALPHA early release, so expect bugs or functions that are still not implemented.

If you want to clone this repository remember that GIT LARGE FILE is used for the essentia-tensorflow models (the .pb file) so you need first to install it on your local machine (supposing a debian based machine)

sudo apt-get install git-lfs
git clone --branch devel https://github.com/NeptuneHub/AudioMuse-AI.git

The large file was created in this way (in case you need to add more):

git lfs install
git lfs track "*.pb"
git add .gitattributes
